Parts |
Specification |
BM-52 |
BM-52LED |
|
Viewing Head |
Monocular head, 45ºinclined,
360ºrotating |
Yes |
Yes |
|
Eyepiece |
Eyepiece WF10X-18mm with
pointer |
Yes |
Yes |
|
Eyepiece WF10X-18mm with
scale |
|
|
|
Eyepiece WF10X-18mm |
|
|
|
Eyepiece WF16X-13mm |
|
|
|
Eyepiece WF20X-11mm |
|
|
|
Eyepiece WF10X with
reticule focusable |
|
|
|
Nosepiece |
Triple nosepiece with positive click
stopper |
Yes |
Yes |
|
Quadruple nosepiece with positive click stopper |
|
|
|
Objective |
DIN
achromatic objective 4X/NA0.10 |
Yes |
Yes |
|
DIN
achromatic objective 10X/NA0.25 |
Yes |
Yes |
|
DIN
achromatic objective 40XR/NA0.65 |
Yes |
Yes |
|
DIN
achromatic objective 60XR/NA0.85 |
|
|
|
DIN
achromatic objective 100XR(oil)/NA1.25 |
|
|
|
Stage |
Plain stage with slide clips ( Stage
size: 110mm X 120mm ) |
Yes |
|
|
Metal stage 110mm X 120mm with movable
specimen holder,
Movable specimen holder in black
or in silver for option |
|
Yes |
|
Condenser |
NA0.65 single lens condenser with Disc
diaphragm |
Yes |
Yes |
|
NA1.25 Abbe
condenser |
|
|
|
Diaphragm |
Disc
diaphragm with five apertures |
|
|
|
Iris
diaphragm |
|
|
|
Focusing |
Coaxial focusing system, with safe rack
stopper |
Yes |
Yes |
|
Power |
an Incandescent Lamp 230V/20W or
115V/20W |
Yes |
|
|
LED lamps, Ni-Cd rechargeable battery
pack, and AC/CD adaptor. The brightness is adjustable. |
|
Yes |
|
Packing |
Each set in a foam in an inner carton, 4
inner cartons in a master carton. |
Yes |
Yes |
|
Aluminium-Alloy Instruments Case |
|
|
|
Wooden case
with lock & keys |
|
|
|
Option |
Photoset for microscope |
|
|
|
Video camera adaptor (C-mount) for microscope |
|
|
|
Infinite Achromatic Objective and Plan Achromatic Objective |
|
|
|
HDCE Digital Camera Eyepiece for
Microscope |
|
|
|
LCD-20 digital microscope |
|
|
|
MDCE Digital Camera Eyepiece |
|
|
|
MVE-10 Video Eyepeice for Microscope |
|
|
